Technical Information
|
|
Product Standard TS EN 817 (Single Control) |
|
Manufacturer Warranty 6 Years (Painted And Coated Products For 2 Years) |
|
Color / Finish Chrome |
|
Aearator Type M22x1 Female Threaded |
|
Flow Rate 7.5 - 9 Lt / Min (3 Bar) |
|
Operation Type Ceramic Disc Cartridge Ø35 mm Without Leg |
|
Acoustic Class II |
|
Control Type Single Control |
|
Installation Connection Type Countertop |
|
Body Raw Material Brass |
|
Spout Height 235 mm |
|
Water Connection Flex Dimension 3/8" |
|
Water Connection Flex Length 42.5 cm |
|
Number Of Control Handle Single |
|
Material Of Control Handle Metal |
|
Dimension Of Base Rosette Ø50 mm |
|
Number Of Loom Holes For Assembly 1 |
|
Loom Hole Diameter Ø33±1 mm |
|
Max. Loom Thickness 40 mm |
|
Max. Performance Temperature 80°C |
|
Suggested Performance Temperature 60°C |
|
Max. Performance Pressure 10 Bar |
|
Suggested Performance Pressure 3 Bar |
|
Min. Performance Pressure 0.5 Bar |
|
Suggested Min. Pressure 1 Bar |
|
Spout / Pipe Type Swivel Spout (Above) |
|
Pipe Height 220 mm |
|
Pipe Length 180 mm |
|
Product Total Height 325 mm |
